AO Smith Pool Cleaner Replacement 0.75 HP Vertical Mount Motor - B663

Product Description

AO Smith Pool Cleaner Replacement Motor 3/4 Horsepower Vertical Mount - B663 features a permanent split capacitor, is switch less, single phase, drip proof, round frame, 3600 RPM and is 3/4 HP.  This pool cleaner replacement motor also includes ball bearings, 60 Hz, 40 degree C ambient, class B insulated, CW non-reversible, 303 stainless steel shaft, "1081" features and aluminum adapter bracket.

Specifications:

• Horsepower:  0.75 HP

• Ambient Temperature:  40 deg C

• Bearing Type:  Ball

• Diameter:  6-1/2 Inch

• Duty Cycle:  Continuous

• Efficiency Group:  Standard

• Enclosure Design:  Open Drip proof

• Finish Color:  Black

• Flange Material:  Aluminum

• Frame:  56Y

• Frequency Rating:  60 Hz

• Full Load Amps:  6.0/12.0 A

• Insulation Class:  B

• Item:  Replacement Pool Cleaner Pump Motor

• Motor Design:  PSC

• Motor Shaft Rotation:  CCWPE

• Motor Thermal Protection:  Auto

• Mounting Position:  Vertical

• Mounting Type:  C-Face, No Base

• Overall Length:  10.89 Inch

• Phase:  1-Phase

• RPM:  3450

• Series:  Arneson Uniseal

• Service Factor:  1.50

• Shaft Design:  Threaded

• Shaft Diameter:  5/8 Inch

• Shaft Length:  7/16 Inch

• Shaft Material:  303 Stainless Steel

• Standards Approvals:  UL 1081 Approved, CSA Certified

• Sub Brand:  Century

• Thrust Horsepower:  1.13

• Type:  CX

• Voltage Rating:  115/230 V
